GML MEDUSA LED Motorized Linear Fixture
One Line. Twelve Directions.
Motorized linear LED fixture with 12 independently controlled moving heads
GML MEDUSA LED Motorized Linear Fixture
GML MEDUSA is a high-output motorized linear LED fixture designed for concert stages, touring productions, television broadcast, and large-scale rental inventory. Measuring 1009 mm in length, the fixture integrates 12 independently moving heads , each equipped with an 80W RGBW 4-in-1 LED, supplemented by a dual linear strobe layer of 360 ...
Specifications
Technical Dimensions
Precise engineering specifications
Technical Dossier
LET’S START WITH THE REQUIREMENTS.
Tell us what you are planning, replacing or trying to solve. A useful first message can include the space, intended use, mounting position, control system, environmental conditions and approximate quantity. We can then point you to suitable fixtures, documentation or the next technical question.
Independent Directions
12 motorized moving heads integrated into a 1009 mm linear bar. Each head operates with independent DMX tilt control across 200°, forming parallel linear arrays or multi-directional beam fans.
Beam to Field
Motorized zoom adjusts beam dispersion from narrow 5.7° spot beams to a 26.8° flood beam (33.9° field angle), enabling transitions between parallel mid-air rays and wide surface illumination.
Pixel Architecture
Dual-layer LED architecture combines 12 × 80W RGBW main light sources with 720 auxiliary White LEDs (360 Warm White + 360 Cool White) for high-speed strobe and pixel mapping.
Individual pixel control across 29 to 282 DMX channels enables precise synchronization between motorized tilt motion and LED chase patterns.
